MDD071B-N-040-N2T-095GL0
MDD Synchronous Motors
Technical Specifications
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
4.4 Nm
Motor Length Code
B
Motor Size
071
Nominal Speed
4000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
How does the left connection affect installation of MDD071B-N-040-N2T-095GL0?
The connection direction is Left and it locates the connector on the left side of the motor. This orientation helps plan cable trays and reduces interference with nearby equipment.
Why is the encoder type important for position recovery with MDD071B-N-040-N2T-095GL0?
The encoder is an embedded multiturn absolute encoder and it stores absolute shaft position across power cycles. This encoder reduces setup time after power interruptions.
What does the centering diameter mean for mounting MDD071B-N-040-N2T-095GL0?
With a centering diameter of 95 mm, the motor fits standard coupling and flange centers. This measurement helps achieve accurate and consistent alignment during assembly.
How does having a shaft seal affect maintenance for MDD071B-N-040-N2T-095GL0?
The shaft seal is With shaft seal and it limits contaminant entry around the shaft. This sealing lowers frequency of bearing inspections and helps preserve internal components.
Why does nominal speed matter when selecting MDD071B-N-040-N2T-095GL0 for an application?
The nominal speed is 4000 min⁻¹ and it defines the rated operating speed for continuous use. This speed guides gearbox and load matching decisions.
Common Misspellings
MDD-071B-N-040-N2T-095GL0
MDD071B N 040 N2T 095GL0
MDD071B-N-040-N2T-095-GL0
MDD071B-N-040-N2T-095-GLO
MDD071B-N-040-N2T-095GLO
MDD071BN040N2T095GL0
MDD71B-N-040-N2T-095GL0
MDDO71B-N-040-N2T-095GL0
MDDO71B-N-O4O-N2T-O95GLO
Internal Product Review
The MDD071B-N-040-N2T-095GL0 offers dependable motion and predictable service life for repetitive tasks. The left connection direction simply is able to help when cable routing must clear equipment on the right side. Build quality supports steady performance in routine industrial use.
