MDD071B-N-060-N2S-095PL0
MDD Synchronous Motors
The MDD071B-N-060-N2S-095PL0 from Bosch Rexroth Indramat delivers 4.4 Nm standstill torque and runs at 6000 min⁻¹. Part of the MDD Synchronous Motors series, it offers digital servo feedback and is supplied without blocking brake. It features a centering diameter of 95 mm with standard balancing.
A left connector and standard housing ensure easy installation. The output shaft follows DIN 6885 keyway specifications. Ideal for digital drive controllers needing robust precision.
Technical Specifications
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
4.4 Nm
Motor Length Code
B
Motor Size
071
Nominal Speed
6000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Output Shaft
Shaft With Keyway Per DIN 6885 sh. 1, 8-68 Edition
Frequently Asked Questions
What is the torque at standstill of the MDD071B-N-060-N2S-095PL0 motor?
The MDD071B-N-060-N2S-095PL0 motor basically provides a continuous torque of 4.4 Nm at a standstill. This torque is crucial in holding positions in cases where specific movement stasis is demanded.
How rapidly can the MDD071B-N-060-N2S-095PL0 motor perform?
The MDD071B-N-060-N2S-095PL0 motor can operate at a nominal speed of 6000 min⁻¹. This speed implies that it can be employed in dynamic roles requiring prompt movement and repetitive actions.
What is the connection approach taken by MDD071B-N-060-N2S-095PL0?
The MDD071B-N-060-N2S-095PL0 motor uses a connector attachment on the left side. This connection is user-friendly and helps in fast and uncomplicated replacement even amidst a working assembly.
What housing option is present in the design of MDD071B-N-060-N2S-095PL0?
The MDD071B-N-060-N2S-095PL0 motor uses a standard housing option. This design allows it to fit flexibly in various industrial installations without hindering durability and performance quality.
How does the shaft seal enhance the working of MDD071B-N-060-N2S-095PL0?
The MDD071B-N-060-N2S-095PL0 comes with a shaft seal component. Such a seal remarkably combats external debris and humidity, thus lengthening the working life of the motor and reducing downtime.
Common Misspellings
MDD-071B-N-060-N2S-095PL0
MDD071B N 060 N2S 095PL0
MDD071B-N-060-N2S-095-PL0
MDD071B-N-060-N2S-095-PLO
MDD071B-N-060-N2S-095PLO
MDD071BN060N2S095PL0
MDD71B-N-060-N2S-095PL0
MDDO71B-N-060-N2S-095PL0
MDDO71B-N-O6O-N2S-O95PLO
Internal Product Review
The MDD071B-N-060-N2S-095PL0 motor works well due to its sturdy design and 4.4 Nm torque at standstill. This feature makes it highly reliable in maintaining position and ensuring consistent performance, particularly in slow or halted operations.
