The Bosch Rexroth Indramat MDD071C-N-030-N2S-095GB0 motor from the MDD Synchronous Motors series is a robust motor for digital drive controllers featuring a motor size of 071 and a motor length code of C. It delivers a continuous torque at standstill of 6.6 Nm at a nominal speed of 3000 min⁻¹ and incorporates digital servo feedback (DSF) for precise control. The unit is supplied without blocking brake and includes a shaft seal with a plain shaft design. The standard housing and 95 mm centering diameter ensure seamless integration, while the side-mounted connector on Side B facilitates reliable connectivity.
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Side B
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
