MDD071C-N-030-N2S-095GR1

MDD Synchronous Motors

Rated 4.9 stars (8 total reviews)
  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The MDD071C-N-030-N2S-095GR1, Bosch Rexroth Indramat, MDD Synchronous Motors device is engineered for precision motion control in demanding industrial applications. It incorporates a Standard Housing and Plain shaft Shaft Type to deliver robust performance and ease of integration. Featuring Digital servo feedback (DSF) Motor feedback, the unit ensures high-resolution position tracking and stable loop control. The compact Motor Size 071 profile and Motor Length Code C support installation in space-constrained assemblies.



With a Continuous Torque at Standstill of 6.6 Nm and a Holding Brake Torque rating of 3.0 Nm, the motor maintains load position during power interruptions thanks to its With blocking brake Holding Brake. It operates at a Nominal Speed of 3000 min⁻¹ and includes a With shaft seal Shaft Seal to guard against contaminants. A 95 mm Centering Diameter ensures accurate mounting, while the Right Connection Direction and factory-fitted Connector Connection Type streamline cabling. Standard Balancing minimizes vibration and prevents alignment drift, delivering smooth torque conversion under variable loads.



Designed for seamless pairing with Bosch Rexroth digital drives, this motor supports quick commissioning and in-field replacement without special tools. The rugged Standard housing, sealed shaft and precise feedback system enhance reliability and reduce maintenance cycles in high-duty environments. Ideal for robotics, packaging machinery, and automated assembly lines, the MDD071C-N-030-N2S-095GR1 delivers consistent performance and simple integration across diverse automation platforms.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
3.0 Nm

Centering Diameter
95 mm

Housing
Standard

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
6.6 Nm

Motor Length Code
C

Motor Size
071

Nominal Speed
3000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Right

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)
