MDD071C-N-030-N2S-095PL0
MDD Synchronous Motors
The Bosch Rexroth Indramat MDD071C-N-030-N2S-095PL0 is a member of the MDD Synchronous Motors series and embodies precision engineering in a compact frame. This motor for digital drive controllers features a motor size 071 with a motor length code C and delivers a continuous torque at standstill of 6.6 Nm at a nominal speed of 3000 min⁻¹. Its permanent magnet-excited design coupled with electronic commutation ensures rapid response and high cyclic load capacity ideal for dynamic automation. The standard housing and sealed construction protect sensitive components in demanding industrial environments.
The MDD071C-N-030-N2S-095PL0 incorporates advanced digital servo feedback (DSF) with optical measurement, providing precise relative position detection and onboard data memory for swift commissioning. The shaft type keyway and shaft seal maintain alignment and prevent contamination, while the shaft end standard (without side B shaft end) supports versatile coupling options. With a centering diameter of 95 mm and standard balancing, mechanical vibrations are minimized, ensuring smooth operation. The unit’s connector style connection type and left connection direction streamline cable management and reduce installation time.
Designed for reliability, this servo motor operates maintenance-free thanks to lifetime lubricated bearings and a brushless rotor assembly. The absence of a holding brake simplifies the drive train and reduces system complexity. Its robust sealed housing withstands exposure to coolants and emulsions, making it suitable for direct mounting within machine environments without additional protective measures.
Technical Specifications
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
