MDD071C-N-030-N2S-095PL1
MDD Synchronous Motors
The Bosch Rexroth Indramat MDD071C-N-030-N2S-095PL1 from the MDD Synchronous Motors series is a high-performance motor for digital drive controllers featuring a motor size 071 frame and a motor length code C designation. It incorporates a centering diameter of 95 mm for precision alignment and a standard balancing process that minimizes vibration and noise across the operating range. The robust housing construction provides mechanical rigidity and thermal stability, while the integrated shaft seal protects internal bearings and windings from dust and moisture intrusion. This compact synchronous motor is engineered for reliable, high-precision motion control in demanding industrial automation applications.
Engineered to deliver smooth torque, the motor offers a continuous torque at standstill of 6.6 Nm, ensuring stable holding under load without drift. It is equipped with blocking brake functionality, delivering a holding brake torque of 3.0 Nm for positive load retention when powered off. High-resolution digital servo feedback (DSF) ensures accurate position and speed monitoring, while the keyway shaft type provides secure torque transmission to downstream components. Standard balancing and premium bearing selection further enhance dynamic performance and extend service life under cyclic operations.
Installation is simplified with a connector-type electrical interface mounted on the left side, reducing cable routing complexity within compact control cabinets. The standard shaft end configuration supports a wide range of coupling and encoder attachments without additional machining. Together, these features yield a versatile, low-maintenance motor solution that integrates seamlessly into Bosch Rexroth Indramat drive systems and supports rapid commissioning across diverse machine architectures.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
3.0 Nm
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
