MDD071C-N-030-N2S-095PR0

The Bosch Rexroth Indramat MDD071C-N-030-N2S-095PR0 from the MDD Synchronous Motors series features a Motor Size 071 frame and a Motor Length Code C housing that measures 288 mm in length. This flange-mounted unit delivers a Nominal Speed of 3000 min⁻¹ with precision digital commutation and is built around a robust Centering Diameter of 95 mm for seamless integration into existing machine tool modules. The motor's exterior is finished in a durable black coating and its standard housing supports both natural convection and surface cooling methods. Designed as a Motor for digital drive controllers, it serves as a core component in cost-effective automation architectures.

With a Continuous Torque at Standstill of 6.6 Nm under natural convection and up to 9.9 Nm with surface cooling, the MDD071C-N-030-N2S-095PR0 maintains impressive thermal performance governed by time constants of 45 minutes and 20 minutes respectively. Equipped with Digital servo feedback (DSF), the motor achieves high-fidelity position and speed regulation without external encoders. The Without blocking brake configuration reduces inertia while retaining mechanical simplicity, and the Shaft Type: keyway design ensures secure coupling to gearboxes or pulleys. Connectivity is optimized via a right-side Connection Type: Connector with a Connection Direction: Right orientation, easing cable routing in compact control cabinets. Standard shaft seal protection and Standard balancing round out a package engineered for minimal vibration and long service life.

Engineered as a robust solution for packaging machinery, gantry systems, and high-precision indexing, this motor excels in continuous and cyclic duty profiles. Its compatibility with Bosch Rexroth digital drive controllers accelerates commissioning through automatic parameter loading and electronic nameplate synchronization. The MDD071C-N-030-N2S-095PR0 combines compact dimensions, high torque density, and advanced feedback into a versatile drive module ready for demanding industrial automation environments.
