The MDD071C-N-030-N2T-095GR0 is a high-performance Digital AC Servo Motor from Bosch Rexroth Indramat within the advanced MDD Synchronous Motors series, designed for precision motion control in demanding industrial environments. This unit features a compact Motor Size: 071 housing with a Motor Length Code: C designation, providing a streamlined footprint for space-constrained installations. Its Nominal Speed: 3000 min⁻¹ rating delivers a balanced combination of speed and torque, with Continuous Torque at Standstill: 6.6 Nm ensuring stable holding capabilities under load. The motor is equipped with a Centering Diameter: 95 mm interface and a robust Shaft Type: Plain shaft configuration for universal coupling options. Engineered without a holding brake, this model offers increased flexibility by eliminating the Holding Brake: Without blocking brake option, making it ideal for applications where passive braking is not required.
Performance is enhanced by the integrated Encoder: Integrated multiturn absolute encoder and Motor feedback: Digital servo feedback (DSF) system, delivering precise commutation, rotor position, and speed control. The motor’s Balancing: Standard specification ensures smooth operation at high rotational speeds, while the Shaft Seal: With shaft seal protects internal components from contaminants. Connectivity is optimized via a right-hand Connection Direction: Right and a secure Connection Type: Connector interface for rapid installation and serviceability. The Housing: Standard design meets rigorous durability standards, supporting continuous operation in varied industrial conditions. With a Shaft End: Standard (without side B shaft end) configuration, this motor seamlessly integrates into existing mechanical assemblies.
Built for reliable integration, the MDD071C-N-030-N2T-095GR0 excels when paired with Bosch Rexroth digital drive controllers, reflecting its designation as a Product Type: Motor for digital drive controllers. Its robust encoder feedback and sealed shaft assembly ensure long-term operational stability and reduced maintenance cycles. The omission of a holding brake simplifies mechanical design and lowers total system cost in applications that rely on active braking solutions. Suitable for robotics, packaging machinery, and CNC systems, this motor delivers the precision, responsiveness, and durability expected from the Rexroth Indramat lineage of motion control solutions.
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Right
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
