The MDD071C-N-030-N2T-095PL0 from Bosch Rexroth Indramat delivers a standstill torque of 6.6 Nm and a size code of 071. Part of the MDD Synchronous Motors series, it spins at 3000 min⁻¹ and has an absolute multiturn encoder. It uses digital servo feedback (DSF) with a keyway shaft.
It includes shaft seal, a 95 mm centering diameter and standard balancing. A left connector simplifies wiring. It’s a motor for digital drive controllers.
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
95 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
