The MDD071C-N-040-N2S-095GA1 servo motor by Bosch Rexroth Indramat is a member of the MDD Synchronous Motors series designed for precision digital drive applications. This Motor for digital drive controllers features a Motor Size of 071 with a Motor Length Code C and a compact Centering Diameter of 95 mm, making it ideal for space-constrained installations. Equipped with Digital servo feedback (DSF), the unit delivers high-resolution position data and supports continuous start-stop operation at a Nominal Speed of 4000 min⁻¹. The motor incorporates a Plain shaft design with a Shaft Seal to prevent ingress of contaminants, and comes With blocking brake for immediate load hold capability. All connections are standardized via Connector interfaces on Connection Direction Side A, simplifying wiring and control integration.
The performance characteristics of the MDD071C-N-040-N2S-095GA1 are optimized for dynamic torque demands, offering Continuous Torque at Standstill of 6.6 Nm and a Holding Brake Torque of 3.0 Nm to maintain load position under power loss. Standard Balancing ensures smooth operation with minimized vibration, while the Standard Housing provides rigid support and thermal conduction for efficient heat dissipation. The motor’s Standard (without side B shaft end) shaft end configuration facilitates direct coupling to gearboxes or encoders without additional adapters. Precise electrical and mechanical coordination is achieved through the integrated digital feedback loop, enabling high repeat accuracy and rapid response in demanding motion profiles. The combination of compact dimensions and high torque density supports acceleration and high-frequency cycling in automated production lines.
Built for long-term reliability, the MDD071C-N-040-N2S-095GA1 motor integrates robust sealing and braking features to withstand industrial environments. Its modular design and standard connector interface accelerate commissioning and maintenance, reducing system downtime. Compatibility with Bosch Rexroth digital drive controllers ensures seamless integration and access to advanced control functions such as auto-tuning and diagnostic monitoring. This servo motor is well-suited for applications in packaging machinery, material handling, robotics, and assembly systems where precision, repeatability, and compact footprint are critical. Its proven digital feedback and holding brake functionality provide engineers with a dependable solution for high-performance motion control tasks.
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
3.0 Nm
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
4000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
