The Bosch Rexroth Indramat MDD071C-N-060-N2S-095GA2 servo motor in the MDD Synchronous Motors series delivers a robust digital AC drive solution with permanent-magnet excitation and integrated encoder-based commutation. Engineered by Bosch Rexroth Indramat, this unit provides a nominal speed of 6000 min⁻¹ and continuous torque at standstill of 6.6 Nm for high-precision positioning tasks. Equipped with a 6.5 Nm blocking brake, it ensures secure holding under load when power is removed. The motor’s plain shaft and standard shaft seal simplify mechanical coupling and protect against contamination. It incorporates a digital servo feedback system to maintain accurate rotor position and speed control throughout dynamic motion profiles.
Detailed technical parameters define the motor’s compact form and performance envelope. It features a Motor Size 071 designation paired with a Motor Length Code C, resulting in a standardized physical envelope. The Centering Diameter of 95 mm aligns with common industrial mounting interfaces. The unit is factory-balanced to Standard tolerance levels and encased in a Standard housing that supports moderate ambient conditions. A plain shaft with a standard (without side B shaft end) profile and shaft seal provides robust mechanical interface. Connectivity is achieved via a Connector on Side A, compatible with digital drive controller inputs.
Operational features emphasize responsive control and reliable performance under variable load conditions. The built-in digital servo feedback (DSF) enables closed-loop control of rotor position and velocity with minimal latency. The permanent-magnet design combined with the encoder ensures consistent commutation and high dynamic torque delivery. The 6.5 Nm blocking brake engages instantaneously for safe stops and maintains axis position during power loss. With a continuous torque rating of 6.6 Nm at standstill, the motor resists external disturbances and supports precise indexing operations.
System integration is optimized for compatibility with Rexroth digital drive controllers and Indramat automation platforms. The part number MDD071C-N-060-N2S-095GA2 interfaces seamlessly with existing Bosch Rexroth control modules, reducing wiring complexity. Target applications include robotic arms, machine tool axes, packaging systems, and semiconductor handling equipment where compact size, high torque density, and precise motion control are critical. This motor’s standardized dimensions and digital feedback capabilities simplify installation and commissioning in advanced industrial automation environments.
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
6.5 Nm
Centering Diameter
95 mm
Housing
Standard
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
6.6 Nm
Motor Length Code
C
Motor Size
071
Nominal Speed
6000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
