MDD090B-N-020-N2L-110GL0

Name: MDD090B-N-020-N2L-110GL0
Brand: Indramat Motors
SKU: MDD090B-N-020-N2L-110GL0
Price: 720.00 USD
Availability: InStock
Rating: 4.8 (13 reviews)

MDD Synchronous Motors

Rated 4.8 stars (13 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth Indramat MDD090B-N-020-N2L-110GL0 from the MDD Synchronous Motors series is a high-precision motor for digital drive controllers featuring a standard housing and a plain shaft with shaft seal. With a centering diameter of 110 mm, this size 090 motor offers a continuous torque at standstill of 7.2 Nm and a nominal speed of 2000 min⁻¹. It is equipped with digital servo feedback (DSF) for accurate position control and includes a standard balancing and a connector in left connection direction. Supplied without a blocking brake, the model has a standard shaft end (without side B shaft end) and is identified by motor length code B.

Technical Specifications

Balancing
Standard

Holding Brake
Without blocking brake

Centering Diameter
110 mm

Housing
Standard

Motor Feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
7.2 Nm

Motor Length Code
B

Motor Size
090

Nominal Speed
2000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

What machines can this motor be used with?

The MDD090B-N-020-N2L-110GL0 is compatible for use with machines that require high precision and an extreme degree of synchronism.

Is the MDD090B-N-020-N2L-110GL0 a low inertial motor?

Yes. The low inertial operation of this motor is partly due the use of rare-earth magnetic material.

Is the MDD090B-N-020-N2L-110GL0 delivered with a connection cable?

No. The connection cable required for the operation of this motor are not delivered with it. They can however be ordered separately.

Are ball bearings used in this motor?

Yes. The MDD090B-N-020-N2L-110GL0 features lifetime lubricated ball bearings.

What material is used for the packaging of the MDD090B-N-020-N2L-110GL0?

The MDD090B-N-020-N2L-110GL0 is packaged and delivered in a recyclable cardboard box. Each package carries a type label that can be used for its identification.

Common Misspellings

MDD-090B-N-020-N2L-110GL0

MDD090B N 020 N2L 110GL0

MDD090B-N-020-N2L-110-GL0

MDD090B-N-020-N2L-110-GLO

MDD090B-N-020-N2L-110GLO

MDD090BN020N2L110GL0

MDD90B-N-020-N2L-110GL0

MDDO90B-N-020-N2L-110GL0

MDDO9OB-N-O2O-N2L-11OGLO

mdd090b-n-020-n2l-110gl0

Internal Product Review

The MDD090B-N-020-N2L-110GL0 synchronous motor is a state-of-the-art product designed by Bosch Rexroth. This motor is self-cooled and belongs to the IP65 protection category. The peak installation altitude for this motor is about 1000 meters above sea level.
