MDD090B-N-020-N2L-110GR0

Name: MDD090B-N-020-N2L-110GR0
Brand: Indramat Motors
SKU: MDD090B-N-020-N2L-110GR0
Price: 752.00 USD
Availability: InStock
Rating: 4.1 (6 reviews)

MDD Synchronous Motors

Rated 4.1 stars (6 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The MDD090B-N-020-N2L-110GR0 motor from Bosch Rexroth Indramat is part of the MDD Synchronous Motors series. It features a centering diameter of 110 mm, a continuous torque at standstill of 7.2 Nm, a nominal speed of 2000 min⁻¹, and comes in a size 090 housing. The motor employs digital servo feedback (DSF) and a plain shaft design for reliable operation. It connects via a right-side connector and is supplied without a blocking brake.

Technical Specifications

Balancing
Standard

Holding Brake
Without blocking brake

Centering Diameter
110 mm

Housing
Standard

Motor Feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
7.2 Nm

Motor Length Code
B

Motor Size
090

Nominal Speed
2000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Right

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

Does the MDD090B-N-020-N2L-110GL0 require frequent maintenance?

This motor is a maintenance free product.

What is the recommended ambient temperature for this unit?

For operation without derating, ambient temperature should not exceed 45 degrees.

What does the varnish covering this motor do?

The black varnish covering the housing of this motor protects it from corrosive liquids like dilute acid, dilute alkali, mineral oil, and lots more.

What is the best mounting orientation for this motor?

The MDD090B-N-020-N2L-110GL0 can be installed in any orientation.

Is the modification of this motor allowed?

Unauthorized modification of the MDD090B-N-020-N2L-110GL0 is not allowed. This will void the warranty and can lead to electrical accident.

Common Misspellings

MDD-090B-N-020-N2L-110GR0

MDD090B N 020 N2L 110GR0

MDD090B-N-020-N2L-110-GR0

MDD090B-N-020-N2L-110-GRO

MDD090B-N-020-N2L-110GRO

MDD090BN020N2L110GR0

MDD90B-N-020-N2L-110GR0

MDDO90B-N-020-N2L-110GR0

MDDO9OB-N-O2O-N2L-11OGRO

Internal Product Review

The MDD090B-N-020-N2L-110GR0 is a low inertial motor manufactured by Bosch Rexroth. This motor is without a blocking brake, however it is equipped with a digital servo feedback. The peak installation altitude for this motor is about 1000 meters above sea level.
