MDD090B-N-020-N2L-110PA1
MDD Synchronous Motors
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
6.5 Nm
Centering Diameter
110 mm
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
7.2 Nm
Motor Length Code
B
Motor Size
090
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
What is the maximum current consumption of this motor?
Under standard conditions, this motor can use up as high as 48.6 amperes of current.
Is the MDD090B-N-020-N2L-110PA1 able to reach a high operation speed?
The nominal speed of this product is about 2000 revolutions per minute.
What is the total weight of this motor?
The MDD090B-N-020-N2L-110PA1 weighs about 18 kilograms.
What is the winding inductance of this product?
During operation, the winding inductance of the motor is about 10.1 millihenry.
Is the MDD090B-N-020-N2L-110PA1 delivered with connection cables?
No. However, ready made cables can be ordered from Wake industrial.
Common Misspellings
MDD-090B-N-020-N2L-110PA1
MDD090B N 020 N2L 110PA1
MDD090B-N-020-N2L-110-PA1
MDD090BN020N2L110PA1
MDD90B-N-020-N2L-110PA1
MDDO90B-N-020-N2L-110PA1
MDDO9OB-N-O2O-N2L-11OPA1
mdd090b-n-020-n2l-110pa1
Internal Product Review
The MDD090B-N-020-N2L-110PA1 is an unique motor design that is able to maintain a nominal speed of 2000 revolutions per minute. At standstill, this motor produces a typical torque of about 10.5 newton meters and operates at a continuous current of 8.3 amperes.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD090B-N-020-N2L-110PA1.
