MDD090B-N-020-N2L-110PL1
MDD Synchronous Motors
The MDD090B-N-020-N2L-110PL1 from Bosch Rexroth Indramat offers a continuous torque at standstill of 7.2 Nm and a maximum torque of 39 Nm. Part of the MDD Synchronous Motors series, this motor features ingress protection IP 65 and a holding brake torque of 6.5 Nm.
It provides digital servo feedback (DSF), has a centering diameter of 110 mm, and includes a standard shaft seal. The motor operates at a nominal speed of 2000 min⁻¹.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
6.5 Nm
Centering Diameter
110 mm
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
7.2 Nm
Motor Size
090
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Connection Direction
Left
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Maximum Torque
39 Nm
Ingress Protection
IP 65
Winding Inductance
1.2 mH
Winding Resistance
0.8 Ohms
Inertia Rating
36 x 10^-4 kgm²
Frequently Asked Questions
How often should the MDD090B-N-020-N2L-110PL1 subjected to maintenance?
The MDD090B-N-020-N2L-110PL1 is a maintenance free device.
How much noise does this motor produce during operation?
The average noise level of the MDD090B-N-020-N2L-110PL1 is between 70 to 75 decibels.
How is this motor shipped to customers abroad?
The shipment of this motor is done through FedEx, UPS, or DHL.
Is the MDD090B-N-020-N2L-110PL1 an energy intensive product?
No. The maximum possible current used by this motor is about 48.6 amperes.
What level of inertial does this motor maintain?
The MDD090B-N-020-N2L-110PL1 is classified as a low inertial product.
Common Misspellings
MDD-090B-N-020-N2L-110PL1
MDD090B N 020 N2L 110PL1
MDD090B-N-020-N2L-110-PL1
MDD090BN020N2L110PL1
MDD90B-N-020-N2L-110PL1
MDDO90B-N-020-N2L-110PL1
MDDO9OB-N-O2O-N2L-11OPL1
mdd090b-n-020-n2l-110pl1
Internal Product Review
The MDD090B-N-020-N2L-110PL1 servo motor is manufactured by Bosch Rexroth. This motor is a low-inertial product that has a thermistor built into its winding for temperature monitoring. The motor is easy to install and can be mounted in any orientation in the servo system.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD090B-N-020-N2L-110PL1.
