MDD093B-N-020-N2L-110PA1
MDD Synchronous Motors
The MDD093B-N-020-N2L-110PA1 is a motor for digital drive controllers from Bosch Rexroth Indramat's MDD Synchronous Motors series. It provides a continuous torque at standstill of 14.5 Nm and a holding brake torque of 11 Nm with blocking brake. Operating at 2000 min⁻¹, it features digital servo feedback (DSF), a 110 mm centering diameter, a keyed shaft with seal, and side A connector.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
11 Nm
Centering Diameter
110 mm
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
14.5 Nm
Motor Length Code
B
Motor Size
093
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
How does the MDD093B-N-020-N2L-110PA1 maintain stability under continuous low-speed torque demand?
It delivers 14.5 Nm of continuous torque at standstill without thermal derating. This enables smooth, steady force in holding and tensioning applications.
Can the MDD093B-N-020-N2L-110PA1 support secure braking during emergency stops in vertical axes?
It integrates an 11 Nm blocking brake for safe load retention. This prevents unintentional shaft movement during power-off or e-stop conditions.
Is feedback resolution sufficient for precise cycle positioning in closed-loop systems?
The motor features digital servo feedback to deliver high-resolution motion data. It supports tight loop response and minimal tracking error during fast position changes.
Does the keyed shaft affect alignment when coupled to backlash-sensitive loads?
This version includes a keyed shaft with a shaft seal for protected and positive mechanical engagement. It ensures torque lock-in while resisting contamination ingress.
Will the MDD093B-N-020-N2L-110PA1 simplify cable routing in forward-panel installations?
The connector is located on Side A to facilitate front-facing control cabinet layouts. This reduces cable clutter and improves access during commissioning.
Common Misspellings
MDD-093B-N-020-N2L-110PA1
MDD093B N 020 N2L 110PA1
MDD093B-N-020-N2L-110-PA1
MDD093BN020N2L110PA1
MDD93B-N-020-N2L-110PA1
MDDO93B-N-020-N2L-110PA1
MDDO93B-N-O2O-N2L-11OPA1
mdd093b-n-020-n2l-110pa1
Internal Product Review
The model MDD093B-N-020-N2L-110PA1 is a digital drive motor from the Bosch Rexroth Indramat MDD series. It delivers a continuous standstill torque of 14.5 Nm. It includes features such as a holding brake torque of 11 Nm, digital servo feedback (DSF), and a 110 mm centering diameter. The motor’s shaft is equipped with a keyed design and seal for enhanced durability.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD093B-N-020-N2L-110PA1.
