MDD093B-N-020-N2M-110GL1
MDD Synchronous Motors
The MDD093B-N-020-N2M-110GL1 is a motor for digital drive controllers by Bosch Rexroth Indramat, part of the MDD Synchronous Motors series. It delivers a continuous torque at standstill of 14.5 Nm and a holding brake torque of 11 Nm, operating at 2000 min⁻¹. Equipped with an integrated multiturn absolute encoder and digital servo feedback (DSF), it features a plain shaft, shaft seal, and left-side connector. Housing and balancing are standard.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
11 Nm
Centering Diameter
110 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
14.5 Nm
Motor Length Code
B
Motor Size
093
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
What role does the blocking brake torque play in industrial applications?
The blocking brake torque helps secure the motor shaft when stationary, preventing unintended motion. This is critical in vertical axis drives and safety-sensitive automation systems.
How does an integrated multiturn absolute encoder improve motor performance?
It provides precise position tracking over multiple revolutions, eliminating the need for homing cycles. This ensures faster startup and consistent accuracy in automated processes.
Why is centering diameter an important specification for installation?
It determines alignment accuracy between the motor and machine housing. A proper fit minimizes vibration and ensures reliable torque transfer.
What distinguishes the Bosch Rexroth Indramat MDD093B-N-020-N2M-110GL1 motor from similar models?
This model combines 14.5 Nm holding torque capability with an integrated absolute encoder and brake system. It is tailored for reliable use in demanding automation and motion-control systems.
How does connection direction affect integration with existing systems?
A left-side connector simplifies wiring layouts in compact installations. This reduces cable stress and allows easier service access.
Common Misspellings
MDD-093B-N-020-N2M-110GL1
MDD093B N 020 N2M 110GL1
MDD093B-N-020-N2M-110-GL1
MDD093BN020N2M110GL1
MDD93B-N-020-N2M-110GL1
MDDO93B-N-020-N2M-110GL1
MDDO93B-N-O2O-N2M-11OGL1
Internal Product Review
The Bosch Rexroth Indramat MDD093B-N-020-N2M-110GL1 motor has a 14.5 Nm continuous torque at standstill, a plain shaft with seal and an integrated multiturn absolute encoder for precise positioning. With its blocking brake torque of 11 Nm, it is widely applied in packaging machinery, printing systems and automation lines.
