MDD093B-N-020-N2M-110PL1

MDD Synchronous Motors

Rated 4.9 stars (8 total reviews)
  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The MDD093B-N-020-N2M-110PL1, Bosch Rexroth Indramat, MDD Synchronous Motors model delivers precision torque for demanding automation and motion-control applications. This motor for digital drive controllers features an integrated multiturn absolute encoder for accurate positioning and digital servo feedback (DSF) for high-resolution control. With a compact center diameter of 110 mm and a standardized housing, it integrates seamlessly into existing machine architectures. The inclusion of a blocking brake enhances safety during power loss and supports controlled deceleration.



Designed to exacting specifications, the motor offers continuous torque at standstill of 14.5 Nm and a holding brake torque of 11 Nm courtesy of the built-in blocking brake. It rotates at a nominal speed of 2000 min⁻¹ while maintaining standard balancing for low-vibration operation. The keyway shaft type with standard (without side B shaft end) configuration ensures compatibility with common couplings and machine components. A shaft seal protects internal bearings from contaminants, and the motor size code 093 and motor length code B define its envelope dimensions. Power and feedback connections are simplified through a left connection direction and a robust connector interface, streamlining installation and service.



Engineers benefit from the motor’s plug-and-play readiness with Bosch Rexroth Indramat digital drive controllers and standardized mounting dimensions, reducing commissioning time. The rugged design, including shaft sealing and blocking brake, guarantees reliable operation in industrial environments and minimizes maintenance intervals. Whether used in conveyors, pick-and-place systems, or automated assembly lines, the MDD093B-N-020-N2M-110PL1 excels in delivering precise motion control under continuous and dynamic load conditions.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
11 Nm

Centering Diameter
110 mm

Housing
Standard

Encoder
Integrated multiturn absolute encoder

Motor feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
14.5 Nm

Motor Length Code
B

Motor Size
093

Nominal Speed
2000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
keyway

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
We offer a repair service for the MDD093B-N-020-N2M-110PL1.
