MDD093B-N-020-N2M-110PR0
MDD Synchronous Motors
Technical Specifications
Balancing
Standard
Holding Brake
Without blocking brake
Centering Diameter
110 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
14.5 Nm
Motor Length Code
B
Motor Size
093
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Right
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
How does encoder integration in this model influence axis recovery during power cycles?
The MDD093B-N-020-N2M-110PR0 uses a multiturn absolute encoder for non-volatile position tracking. This enables precise homing and eliminates the need for external reference sensors.
What design constraints does the lack of an internal brake introduce for vertical load axes?
This model omits a holding brake, which affects load retention during power-off states. Integrators must include external braking elements for safe static positioning.
What are the retrofit alignment implications when using this synchronous motor in existing assemblies?
The MDD093B-N-020-N2M-110PR0 includes a 110 mm centering diameter, defining its axial mounting profile. Accurate seat machining is critical for precise shaft alignment and minimal vibration.
How should cabling layout be adjusted when this motor is used in high-density drive cabinets?
The connector is mounted on the right side, requiring lateral space for routing. Poor clearance planning may introduce stress on terminations or limit accessibility during service.
Can the motor maintain mechanical output in thermally intensive environments under constant duty?
The MDD093B-N-020-N2M-110PR0 delivers 14.5 Nm of continuous torque at standstill. Its thermal envelope supports sustained load, but ambient airflow and enclosure design remain critical.
Common Misspellings
MDD-093B-N-020-N2M-110PR0
MDD093B N 020 N2M 110PR0
MDD093B-N-020-N2M-110-PR0
MDD093B-N-020-N2M-110-PRO
MDD093B-N-020-N2M-110PRO
MDD093BN020N2M110PR0
MDD93B-N-020-N2M-110PR0
MDDO93B-N-020-N2M-110PR0
MDDO93B-N-O2O-N2M-11OPRO
Internal Product Review
The model MDD093B-N-020-N2M-110PR0 from Bosch Rexroth Indramat delivers precise motion control with its 110 mm centering diameter. It ensures 14.5 Nm torque at standstill, includes a multiturn absolute encoder, and connects via a right-side connector. It is fully compatible with Rexroth's DDS and DKS drive controller series.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD093B-N-020-N2M-110PR0.
