MDD093B-N-020-N2M-110PR1
MDD Synchronous Motors
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
11 Nm
Centering Diameter
110 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
14.5 Nm
Motor Length Code
B
Motor Size
093
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Right
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
What factors should be considered when using the MDD093B-N-020-N2M-110PR1 in safety-critical vertical axes?
This model integrates an 11 Nm blocking brake to hold position under static load. It improves vertical stability, but brake wear under cyclic loads must be factored into lifecycle planning.
How does this motor preserve absolute position without re-referencing after power cycles?
The MDD093B-N-020-N2M-110PR1 uses an integrated multiturn absolute encoder. It ensures accurate position tracking across shutdowns, eliminating the need for homing routines.
Can thermal behavior under continuous duty affect long-term output consistency?
It sustains 14.5 Nm of continuous torque at standstill, optimized for high-duty cycles. However, proper thermal management is essential to avoid output degradation over time.
What mechanical fit tolerances are essential when mounting this synchronous motor in aligned assemblies?
The motor features a 110 mm centering diameter, setting its mounting interface. Precise seat machining is crucial to maintain shaft concentricity and minimize oscillation under load.
How does connector orientation influence layout constraints in compact machine frames?
The MDD093B-N-020-N2M-110PR1 places its connector on the right side. This requires careful clearance planning to avoid lateral cable stress or interference with adjacent components.
Common Misspellings
MDD-093B-N-020-N2M-110PR1
MDD093B N 020 N2M 110PR1
MDD093B-N-020-N2M-110-PR1
MDD093BN020N2M110PR1
MDD93B-N-020-N2M-110PR1
MDDO93B-N-020-N2M-110PR1
MDDO93B-N-O2O-N2M-11OPR1
Internal Product Review
The MDD093B-N-020-N2M-110PR1 synchronous motor is designed and manufactured by Bosch Rexroth. It comes with a 110 mm centering diameter. It provides 14.5 Nm continuous torque, features a multiturn absolute encoder, and connects via the right side. The motor includes an 11 Nm blocking brake for secure holding.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD093B-N-020-N2M-110PR1.
