MDD093B-N-040-N2L-110GR0
MDD Synchronous Motors
Rated 4.3 stars (6 total reviews)
The MDD093B-N-040-N2L-110GR0 is a synchronous servo motor produced by Bosch Rexroth Indramat within the MDD Synchronous Motors series. As a motor for digital drive controllers, it delivers closed-loop torque and velocity control to automated axes found in packaging, printing, and material-handling equipment, where quick reversals and cycle-to-cycle accuracy are essential. Its electrical and mechanical features are tuned to pair directly with Rexroth drive amplifiers without additional adaptation.
It generates a continuous standstill torque of 14.5 Nm, allowing the axis to hold or slowly index heavy loads without overheating. Under commanded conditions the rotor can reach a nominal speed of 4000 min⁻¹, a figure that defines the top repetitive velocity before derating is required. Position feedback is provided through Digital servo feedback, supplying the drive with high-resolution angle data for tight current loops. Power and encoder cables exit on the Right side, and the specified Connector interface simplifies field replacement or pre-assembly harnessing. For systems that rely on mechanical clamping or dynamic braking at the inverter, the motor is supplied without a blocking brake, removing static friction and reducing stack length. Standard electromagnetic balancing and a sealed housing keep vibration and contamination within the limits expected for high-speed servo use.
Mechanical fit is determined by a centering diameter of 110 mm, ensuring coaxial alignment with gearboxes or flange plates. The rotor is coupled through a plain shaft that arrives with a factory-installed shaft seal to protect internal bearings from coolant or dust ingress. Compact envelope dimensions follow the naming convention, with motor size 093 and length code B establishing a frame that can be mounted in restricted cabinet spaces or on moving gantries. The housing remains standard, and the single-ended shaft arrangement avoids the need for a side-B interface, simplifying coupler design while keeping inertia low.
Technical Specifications
Balancing
Standard
Blocking Brake
Without Blocking Brake
Centering Diameter
110 mm
Connection Direction
Right
Connection Type
Connector
Continuous Torque at Standstill
14.5 Nm
Holding Brake
Without blocking brake
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Motor For Digital Drive Controllers
MDD
Motor Length Code
B
Motor Size
093
Nominal Speed
4000 min⁻¹
Output Shaft
Plain Shaft
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Frequently Asked Questions
Common Misspellings
Internal Product Review
The Bosch Rexroth Indramat MDD093B-N-040-N2L-110GR0 motor provides 14.5 Nm continuous torque at standstill and operates at 4000 min⁻¹. It includes digital servo feedback, plain shaft, and shaft seal for reliable operation. Right-side connector, standard housing, and 110 mm centering diameter ensure accurate positioning and integration with digital drive controllers.
