MDD093C-N-030-N2L-110GL1

MDD Synchronous Motors

Rated 4.2 stars (5 total reviews)
  In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The MDD093C-N-030-N2L-110GL1, Bosch Rexroth Indramat, MDD Synchronous Motors series motor delivers precise torque and speed control for advanced automated systems. Manufactured by Bosch Rexroth Indramat, this high-performance motor for digital drive controllers combines rugged construction with digital integration. Its standard housing and compact footprint simplify installation in multi–axis assemblies, while the 110 mm centering diameter ensures exact alignment. The plain shaft interface and modular connector layout reduce mechanical and electrical coupling time.



Equipped with digital servo feedback (DSF), the motor provides high-resolution position and velocity monitoring, and standard balancing minimises vibration at the 3000 min⁻¹ nominal speed. A refined plain shaft design coupled with an integrated shaft seal offers durable operation in dusty or lubricated environments. A built-in blocking brake rated at 11 Nm holding torque secures stationary loads without external components, and the standard housing preserves enclosure integrity. The C motor length code and 093 motor size strike an optimal balance between torque density and compactness, while left-hand connection direction and a standard shaft end support rapid integration with existing drive infrastructures.



Designed for seamless use with Bosch Rexroth Indramat digital drive controllers, this motor accelerates commissioning and simplifies predictive maintenance through built-in feedback channels. The robust construction and consistent performance ensure high availability in packaging, material handling, and process automation applications. Its standard architecture and connectorized design reduce spare-part varieties and streamline inventory management across machine fleets.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
11 Nm

Centering Diameter
110 mm

Housing
Standard

Motor Feedback
Digital servo feedback (DSF)

Motor Length Code
C

Motor Size
093

Nominal Speed
3000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
Plain shaft

Connection Direction
Left

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)
