MDD093C-N-030-N2M-110GL1
MDD Synchronous Motors
The Bosch Rexroth Indramat MDD093C-N-030-N2M-110GL1 from the MDD Synchronous Motors series is a precision-engineered motor for digital drive controllers designed to meet demanding automation requirements. This 093-frame motor, denoted by the Motor Length Code C, delivers a nominal speed of 3000 min⁻¹ with exceptional stability under variable loads. Equipped with an integrated multiturn absolute encoder, it provides accurate position feedback across multiple revolutions without homing cycles. Native compatibility with modern digital architectures is ensured through built-in Digital servo feedback (DSF).
Mechanical versatility is a hallmark of this design. The motor’s plain shaft with shaft seal protects internal bearings from contaminants, while the centering diameter of 110 mm guarantees precise alignment in coupling configurations. A robust housing (standard) offers IP protection suited for industrial environments, and factory-balanced rotors minimize vibration at high speeds. The holding brake with blocking brake supplies a retaining torque of 11 Nm, ensuring reliable load retention when de-energized. Electrical connections are simplified by the left connection direction and a standardized connector interface that accelerates installation and reduces wiring errors.
Engineered for seamless integration, the MDD093C-N-030-N2M-110GL1 excels in both new and retrofit projects. Standard balancing procedures optimize dynamic performance, reducing wear on drive components, while the absence of a side B shaft end facilitates mounting in compact assemblies. The combination of absolute encoder precision, integrated DSF feedback, and Bosch Rexroth Indramat’s rigorous quality standards makes this motor an ideal choice for high-performance servo applications in packaging, printing, and pick-and-place systems.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
11 Nm
Centering Diameter
110 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Motor Length Code
C
Motor Size
093
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
Plain shaft
Connection Direction
Left
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Common Misspellings
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD093C-N-030-N2M-110GL1.
