MDD093C-N-030-N2M-130PA1
MDD Synchronous Motors
The MDD093C-N-030-N2M-130PA1 is a motor for digital drive controllers manufactured by Bosch Rexroth Indramat, part of the MDD Synchronous Motors series. It features a nominal speed of 3000 min⁻¹, holding brake torque of 11 Nm with a blocking brake, and an integrated multiturn absolute encoder for precise feedback. The housing employs standard balancing, a keyway shaft with seal, side A connector, digital servo feedback (DSF), a centering diameter of 130 mm, motor length code C, and a standard shaft end.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
11 Nm
Centering Diameter
130 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Motor Length Code
C
Motor Size
093
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side A
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
How does the shaft seal in the MDD093C-N-030-N2M-130PA1 improve motor reliability?
The shaft seal prevents contaminants like dust or oil from entering the motor housing. This ensures longer service life and consistent performance in demanding environments.
Why is the keyway shaft type used in the MDD093C-N-030-N2M-130PA1?
The keyway design provides a secure mechanical connection between the motor shaft and the driven component. It minimizes slippage, ensuring precise torque transfer.
What is the role of the side A connector in the MDD093C-N-030-N2M-130PA1?
The side A connector simplifies installation and space management in machine layouts. It allows quick and reliable electrical connections with minimal downtime.
How does the integrated multiturn absolute encoder support the MDD093C-N-030-N2M-130PA1?
The encoder tracks shaft position across multiple revolutions without needing a reference reset. This ensures accurate positioning even after power loss.
Why is digital servo feedback (DSF) important in the MDD093C-N-030-N2M-130PA1?
DSF provides real-time communication between the motor and the controller for precise speed and torque regulation. It enhances motion accuracy and overall system efficiency.
Common Misspellings
MDD-093C-N-030-N2M-130PA1
MDD093C N 030 N2M 130PA1
MDD093C-N-030-N2M-130-PA1
MDD093CN030N2M130PA1
MDD93C-N-030-N2M-130PA1
MDDO93C-N-030-N2M-130PA1
MDDO93C-N-O3O-N2M-13OPA1
Internal Product Review
The MDD093C-N-030-N2M-130PA1 by Bosch Rexroth Indramat is a heavy-duty motor intended for digital drive controllers. This motor comes with a multiturn absolute encoder featuring DSF and has an 11 Nm holding brake integrated into it. This motor finds maximum application in high-end packaging equipment and automated material handling systems.
