MDD093C-N-030-N2M-130PB0

The Bosch Rexroth Indramat MDD093C-N-030-N2M-130PB0 is a high-precision servo motor in the MDD Synchronous Motors series, designed for digital drive controllers in demanding industrial automation applications. This motor delivers a nominal speed of 3000 min⁻¹ and features digital servo feedback (DSF) paired with an integrated multiturn absolute encoder to ensure accurate position and velocity control. The robust standard housing meets IP65 protection class requirements and is finished with a corrosion-resistant black coating to guard against dilute acids, alkalis, hydraulic oils, and ambient contaminants. With no blocking brake installed, the MDD093C-N-030-N2M-130PB0 maintains a compact footprint and optimized cooling characteristics for continuous operation in production environments. This unit’s design supports consistent low-noise operation, enabling uninterrupted use in noise-sensitive settings.

Technical specifications for the MDD093C-N-030-N2M-130PB0 are comprehensive and precisely defined. The motor’s motor size of 093 and motor length code C combine to yield a centering diameter of 130 mm. It employs a keyway shaft type with an integrated shaft seal for enhanced protection and durability under harsh conditions. Connections are facilitated via a side-mounted connector connection type on Side B, while the opposite side retains a standard shaft end without additional outlets. Balancing is performed to standard tolerances, ensuring minimal vibration during high-speed operation, and the entire assembly conforms to American and European quality standards.

Operational features emphasize environmental resilience and consistent performance. The motor operates reliably within an ambient temperature range of 0 to 40°C, with storage and transportation ratings up to 80°C. Its housing accommodates an optional external coating layer up to 40 μm thick for further chemical resistance. Despite lacking a holding brake, the unit’s well-engineered magnetic design and standard balancing minimize torque ripple and deliver smooth acceleration profiles. The integration of the multiturn encoder and DSF feedback loop ensures rapid response times and accurate tracking, even under variable load conditions.

System integration is streamlined by the MDD093C-N-030-N2M-130PB0’s compatibility with Bosch Rexroth Indramat digital drive controllers, benefiting from plug-and-play connector interfaces and standardized mounting flanges. As a dedicated motor for digital drive controllers, it is suited to applications such as CNC machine tools, robotic assembly lines, packaging machinery, and automated material handling systems. The unit’s combination of precise motion control, robust environmental protection, and standardized mechanical interfaces makes it an ideal choice for modern industrial automation tasks.
