MDD112C-N-030-N2L-130PB1

Name: MDD112C-N-030-N2L-130PB1
Brand: Indramat Motors
SKU: MDD112C-N-030-N2L-130PB1
Price: 770.00 USD
Availability: InStock
Rating: 4.1 (4 reviews)

MDD Synchronous Motors

Rated 4.1 stars (4 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth Indramat MDD112C-N-030-N2L-130PB1 belongs to the MDD Synchronous Motors series and features digital servo feedback. It delivers 28.0 Nm continuous torque at standstill and 14.0 Nm holding brake torque, using a 130 mm centering diameter. It features a keyway shaft with shaft seal and a side B connector.

Technical Specifications

Balancing
Standard

Holding Brake
With blocking brake

Holding Brake Torque
14.0 Nm

Centering Diameter
130 mm

Housing
Standard

Motor Feedback
Digital servo feedback (DSF)

Continuous Torque at Standstill
28.0 Nm

Motor Length Code
C

Motor Size
112

Nominal Speed
3000 min⁻¹

Shaft Seal
With shaft seal

Shaft Type
keyway

Connection Direction
Side B

Connection Type
Connector

Product Type
Motor for digital drive controllers

Shaft End
Standard (without side B shaft end)

Frequently Asked Questions

How does the Bosch Rexroth MDD112C-N-030-N2L-130PB1 motor's encoder contribute to its performance?

The encoder on the MDD112C-N-030-N2L-130PB1 motor continuously measures speed and sends data to the servo controller for precise motor control.

What is the nominal speed rating of the Bosch Rexroth Indramat MDD112C-N-030-N2L-130PB1 motor?

The nominal speed rating of the MDD112C-N-030-N2L-130PB1 motor is 3000 RPM, ensuring high operational efficiency for industrial automation.

Does the Bosch Rexroth MDD112C-N-030-N2L-130PB1 motor support digital servo feedback?

Yes, the MDD112C-N-030-N2L-130PB1 motor supports digital servo feedback for precise control over motor speed and performance parameters.

What is the protection rating of the Bosch Rexroth MDD112C-N-030-N2L-130PB1 motor?

The MDD112C-N-030-N2L-130PB1 motor has a protection rating of IP65, ensuring resistance to dust and water for harsh industrial environments.

How does the optional brake on the Bosch Rexroth MDD112C-N-030-N2L-130PB1 motor enhance safety?

The brake prevents unwanted motor movement and only allows shaft rotation when a 24V DC signal is applied, improving safety in applications requiring motor holding.

Common Misspellings

MDD-112C-N-030-N2L-130PB1

MDD112C N 030 N2L 130PB1

MDD112C-N-030-N2L-130-PB1

MDD112C-N-O3O-N2L-13OPB1

MDD112CN030N2L130PB1

mdd112c-n-030-n2l-130pb1

Internal Product Review

The Bosch Rexroth Indramat MDD112C-N-030-N2L-130PB1 is a synchronous servo motor from the MDD series. It offers a nominal speed of 3000 RPM and a holding brake torque of 14 Nm. Its uses are found in electromechanical industrial automation and in aircraft machines for speed control in various applications.
