MDD112C-N-030-N2M-130PB1
MDD Synchronous Motors
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
14.0 Nm
Centering Diameter
130 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
28.0 Nm
Motor Length Code
C
Motor Size
112
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side B
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Frequently Asked Questions
What mechanical stress limits are defined for Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor shaft during direct coupling?
The shaft is rated for specific radial and axial force thresholds exceeding these leads to bearing overload, encoder misalignment, and possible premature failure of housing seals.
How is thermal stability managed in Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor under 28 Nm continuous standstill torque?
The stator windings incorporate optimized copper fill and lamination cooling channels, ensuring uniform dissipation of I²R losses and preventing thermal saturation during prolonged stall conditions.
What is the recommended mounting orientation for Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor in automation equipment?
The motor can be mounted horizontally or vertically, but adequate ventilation and encoder cable strain relief must be maintained to prevent heat accumulation and connector fatigue.
How does the housing standard of Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor protect internal assemblies?
The standard housing provides IP-rated sealing against dust and coolant ingress, ensuring that winding insulation and encoder electronics remain unaffected in harsh machine-tool environments.
What effect does nominal speed of 3000 min⁻¹ have on Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor efficiency?
At 3000 min⁻¹, the rotor achieves balanced operational zones, ensuring synchronous torque conversion efficiency, reduced iron losses, and minimal harmonic distortion in servo applications.
Common Misspellings
MDD-112C-N-030-N2M-130PB1
MDD112C N 030 N2M 130PB1
MDD112C-N-030-N2M-130-PB1
MDD112C-N-O3O-N2M-13OPB1
MDD112CN030N2M130PB1
mdd112c-n-030-n2m-130pb1
Internal Product Review
The Bosch Rexroth Indramat MDD112C-N-030-N2M-130PB1 motor is a reliable member of the MDD series. It has a size 112 frame with 28 Nm consistent torque and delivers accurate digital servo feedback. This motor is suited for PLC controllers and automation systems where positioning accuracy, speed consistency, and load stability are required.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD112C-N-030-N2M-130PB1.
