MDD112D-N-020-N2M-130GA1

MDD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MDD112D-N-020-N2M-130GA1 is a dynamic and efficient model of the MDD servomotor series, incorporating Indramat’s advanced digital intelligent drive controllers. Ideal for continuous start-stop operations, it provides exceptional performance and a high rate of cycling without succumbing to fatigue. The motor is protected by an IP 65-rated housing, ensuring its resistance against damage from external touch, dust, and water jets. With its operational reliability further enhanced by the resilient black prime varnish, it showcases superior resistance to varying weather conditions, yellowing, build-up of chalkiness, lye, and diluted acids. It also includes an integrated multiturn absolute encoder for accurate indirect position evaluation and a data memory for storage of operational parameters, ensuring the motor can run safely from startup. The MDD112D-N-020-N2M-130GA1's brushless design and lifetime-lubricated bearings contribute to its maintenance-free operation, with a projected service life of 30,000 operational hours. Its bearings support high radial loads, allowing direct attachment of pinions and belt pulleys to the motor shaft, which is plain for zero-backlash shaft-hub connections.
