MDD112D-N-020-N2M-130PB1
MDD Synchronous Motors
The Bosch Rexroth Indramat MDD112D-N-020-N2M-130PB1 high-performance servo motor from the MDD Synchronous Motors series is engineered for precision motion control in demanding industrial applications. This Motor for digital drive controllers integrates an array of advanced components within a rugged Standard Housing to withstand harsh factory environments. Delivering robust mechanical output with a compact Motor Size of 112 and a precise Centering Diameter of 130 mm, it establishes a new benchmark in performance-to-size ratio. An integrated multiturn absolute encoder provides accurate position feedback directly at the motor shaft, simplifying system design and calibration.
Built for continuous operation, the MDD112D-N-020-N2M-130PB1 sustains a Continuous Torque at Standstill of 38.0 Nm at a Nominal Speed of 2000 min⁻¹ while maintaining Standard Balancing to minimize vibration and noise. A built-in With blocking brake offers rapid load holding, delivering a Holding Brake Torque of 14.0 Nm for secure stops under load. The motor feedback system utilizes Digital servo feedback (DSF) for deterministic control loops, and the sealed With shaft seal design protects internal components against contaminants. A robust keyway Shaft Type and Standard (without side B shaft end) configuration ensure compatibility with existing shafts, while a Side B Connection Direction and modular Connector Connection Type enable straightforward wiring and maintenance.
Integration is seamless with Bosch Rexroth digital drives and motion controllers, leveraging the motor’s embedded encoder and DSF interface for plug-and-play commissioning. The sealed housing and integrated brake enhance reliability, reducing downtime in automated production lines. Ideal for robotics, packaging machinery, and CNC applications, the MDD112D-N-020-N2M-130PB1 offers high torque density, precise feedback, and robust durability for next-generation motion systems.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
14.0 Nm
Centering Diameter
130 mm
Housing
Standard
Encoder
Integrated multiturn absolute encoder
Motor feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
38.0 Nm
Motor Length Code
D
Motor Size
112
Nominal Speed
2000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side B
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
Common Misspellings
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MDD112D-N-020-N2M-130PB1.
