MDD112D-N-020-R2L-130GA1

MDD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MDD112D-N-020-R2L-130GA1 is a robust AC servo motor from Bosch Rexroth, renowned for its cost-effectiveness and superior-quality components. At a weight of 59 kg, this motor model features a rotor with a moment of inertia of 230 x 10-4 kgm2. The motor is equipped with a built-in temperature sensor that prevents it from overheating. With a well-conducted thermal conduction capability, it provides an optimized torque-inertia ratio and high load abilities. The motor should be kept in a dry, dust-free, and shock-free environment for optimal performance. Equipped with safety coverings for the connector housing and output shaft, it ensures protection against moisture and damage. This motor has a 130mm centering diameter and provides digital servo feedback. It also features a standard shaft sealing ring, preventing liquid infiltration into the motor housing. The motor has a balancing class of R, a maximum activity cycle duration of fifteen minutes. Additionally, it includes a 3.5 kg blocking brake and an insulation category of F. This cost-effective AC servo motor offers an optimal solution in various mechanical applications. Offered by Indramat USA, the MDD112D-N-020-R2L-130GA1 comes with a one-year warranty.
