MDD Synchronous Motors | Indramat Motors
MDD112D-N-030-N2L-130GA2
In Stock, Ships 2-3 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
1 Year Warranty Included
Free Ground Shipping
Or speak to a sales representative for additional information:
Phone:
1-888-551-3082
1-888-551-3082
Email:
[email protected]
[email protected]
Description
The MDD112D-N-030-N2L-130GA2 is a Bosch Rexroth servo motor from the MDD series, known for its durability and operational reliability. Featuring an electronically commutated design, it delivers high cyclic load capacity, making it ideal for continuous start-stop operations with high repetition frequencies. Its brushless design and lifetime-lubricated bearings support a lengthy operational lifespan. The servo motor is housed in a sealed case, offering an IP 65 protection level, which safeguards against dust and water jet penetration. With a nominal speed of 3,000 rpm, its performance is optimized by digital servo feedback, ensuring accurate evaluation of relative indirect positioning. This servo motor also includes an optical encoder system with a ± 0.5 angular minute precision, eliminating the need for a dedicated incremental encoder. An integrated data storage module hosts critical information, reducing boot-up times. The MDD112D-N-030-N2L-130GA2 utilizes natural convection and surface cooling for thermal management alongside an internal thermal sensor that assists in avoiding overheating. Finally, its plain output shaft guarantees a non-positive shaft-hub connection, ensuring zero backlash.
MDD Motor Type: Permanent magnet-excited servo motor
Suitable For: Machine tools, robotics, and printing machines
Function: High cyclic load capacity
Design: Brushless, lifetime-lubricated bearings
Housing Ingress Protection Rating: IP 65 in line with DIN 40 050
Cable Ingress Protection Rating: Corresponds with IP 65 category
Nominal Speed: 3,000 revolutions per minute
Encoder System Accuracy: ±0.5 angular minutes
Data Storage: Stores type name and control loop parameters
Cooling Method: Natural convection and surface cooling
Thermal Monitoring: Stator with a sensitive thermal senso
Suitable For: Machine tools, robotics, and printing machines
Function: High cyclic load capacity
Design: Brushless, lifetime-lubricated bearings
Housing Ingress Protection Rating: IP 65 in line with DIN 40 050
Cable Ingress Protection Rating: Corresponds with IP 65 category
Nominal Speed: 3,000 revolutions per minute
Encoder System Accuracy: ±0.5 angular minutes
Data Storage: Stores type name and control loop parameters
Cooling Method: Natural convection and surface cooling
Thermal Monitoring: Stator with a sensitive thermal senso
MDD112DN030N2L130GA2
MDD112D N 030 N2L 130GA2
mdd112d-n-030-n2l-130ga2
MDD112D N 030 N2L 130GA2
mdd112d-n-030-n2l-130ga2
