MDD115C-N-030-N2L-130PB1
MDD Synchronous Motors
MDD115C-N-030-N2L-130PB1, Bosch Rexroth Indramat, MDD Synchronous Motors series offers a high-performance digital AC servo solution tailored for demanding industrial applications. This motor combines a robust brushless design with lifetime-lubricated bearings to ensure maintenance-free operation and extended service life. Equipped with an integrated blocking brake, it delivers precise holding torque while resisting unintended movement when power is removed. Its compact outline and standardized housing simplify installation into existing motion control systems.
Detailed specifications of the MDD115C-N-030-N2L-130PB1 highlight its technological sophistication: it features Digital servo feedback (DSF) for closed-loop control, guaranteeing accurate positioning and dynamic response. The motor delivers a Continuous Torque at Standstill of 47.0 Nm and a Holding Brake Torque of 45.0 Nm, supported by a standard Balancing grade to minimize vibration at high speeds. With a Centering Diameter of 130 mm and Motor Size 115, this unit fits seamlessly in modular drive cabinets. It operates at a Nominal Speed of 3000 min⁻¹ and includes a Shaft Seal to protect internal components against contaminants. The Connection Type is via robust connectors, and the unit ships in a standard Housing rated for industrial conditions.
Integration into digital drive controllers is streamlined thanks to its standardized Product Type interface, enabling plug-and-play pairing with Bosch Rexroth Indramat drives. The side-B connector orientation and keyway Shaft Type ensure secure mechanical coupling and simplified wiring. The rugged design and precise feedback technology enhance system reliability, reducing commissioning time and maintenance overhead. Ideal for robotics, packaging, and CNC machinery, the MDD115C-N-030-N2L-130PB1 delivers consistent performance in continuous and intermittent duty cycles.
Technical Specifications
Balancing
Standard
Holding Brake
With blocking brake
Holding Brake Torque
45.0 Nm
Centering Diameter
130 mm
Housing
Standard
Motor Feedback
Digital servo feedback (DSF)
Continuous Torque at Standstill
47.0 Nm
Motor Length Code
C
Motor Size
115
Nominal Speed
3000 min⁻¹
Shaft Seal
With shaft seal
Shaft Type
keyway
Connection Direction
Side B
Connection Type
Connector
Product Type
Motor for digital drive controllers
Shaft End
Standard (without side B shaft end)
