R911247267 (MDD065A-N-040-N2L-095GA0)

MDD Synchronous Motors

Rated 4.9 stars (4 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch R911247267 (MDD065A-N-040-N2L-095GA0) is a digital AC servo motor, designed for applications such as roller feeds for different manufacturing machines and tool changing devices. Components of this MDD motor include a rotor shaft, stator with winding, core with permanent magnets, encoder, and optional blocking brake. Its servomechanism accepts digital feedback, and a complementary blocking brake can be sourced separately. Power is supplied via a cable connecting at side A of the housing, leading to a non-embellished main motor shaft. Motors with a keyway shaft design are also offered. With a protection rating of IP65, this reliable motor has a nominal speed of 4000 RPM, providing continuous torque and current at standstill of 0.8 Nm and 1.8 Amps respectively. The motor operates at an ambient temperature range of 0 to 45 degrees Celsius and is designed for natural convection or surface cooling. The centering diameter is 95mm and the black-painted housing weighs around 3.2kg.

Technical Specifications

Type
Digital AC Servo Motor

Feedback Type
Digital Servo Feedback

Brake
No (Optional)

Connection
Power socket on side A of housing

Shaft Style
Plain (Keyway Optional)

Protection Rating
IP65

Nominal Speed
4000 RPM

Continuous Torque at Standstill
0.8 Nm

Continuous Current at Standstill
1.8 Amps

Maximum Torque
2.3 Nm

Maximum Current
8.1 Amps

Rotor Inertia
0.00014 kg m2

Torque Constant
0.44 Nm/A at 20 degrees Celsius

Resistance of Winding
16 Ohms at 20 degrees Celsius

Inductance of Winding
20.3 millihenry

Thermal Time Constant
30 minutes

Shipping Weight
Approximately 3.2 kilograms

Ambient Temperature for Operation
0 to 45 degrees Celsius

Housing Cooling Method
Natural convection or surface cooling

Centering Diameter
95 millimeters

Color
Black
