R911256377 (MDD093C-N-030-N2L-110GR0)

Name: R911256377 (MDD093C-N-030-N2L-110GR0)
Brand: Indramat Motors
SKU: MDD093C-N-030-N2L-110GR0
Price: 861.00 USD
Availability: InStock
Rating: 4.9 (13 reviews)

MDD Synchronous Motors

Rated 4.9 stars (13 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911256377 (MDD093C-N-030-N2L-110GR0) is a Bosch Rexroth servo motor designed for use with digital drive controllers. This model has a frame size of 093, length code C, and a standard housing with a centering diameter of 110 mm. It operates at a nominal speed of 3000 min⁻¹ with a plain shaft and shaft seal. The rotor employs rare-earth or iron oxide permanent magnets for low inertia. Motor feedback is provided via digital servo feedback (DSF). The unit is balanced to standard and does not include a blocking brake. It features IP65 ingress protection, insulation class F, and functions within ambient temperatures of 0 to 45 °C and at elevations up to 1000 m.

Technical Specifications

Material
Rare-earth or Iron oxide magnetic materials

Protection Rating
IP65

Temperature Sensor
Integrated

Installation
Any orientation

Frame Size
093

Frame Length
C

Design Type
Standard

Cooling
Natural convection or Surface cooling

Nominal Speed
3000 RPM

Output Shaft
Plain, without blocking brake

Servo Feedback
Digital

Power Connection
Right side

Ambient Temperature
0-45 degrees Celsius

Installation site elevation
0-1000 meters

Insulation Class
F

Frequently Asked Questions

Does MDD093C-N-030-N2L-110GR0 include a holding brake?

No, the MDD093C-N-030-N2L-110GR0 motor is supplied without a brake.

Which direction is the connector on MDD093C-N-030-N2L-110GR0?

The connector for MDD093C-N-030-N2L-110GR0 is positioned to the right.

What is the motor size for MDD093C-N-030-N2L-110GR0?

The MDD093C-N-030-N2L-110GR0 is a size 093 motor.

Does MDD093C-N-030-N2L-110GR0 come with a shaft seal?

Yes, the MDD093C-N-030-N2L-110GR0 is designed with a shaft seal.

What feedback system is included in MDD093C-N-030-N2L-110GR0?

The MDD093C-N-030-N2L-110GR0 includes DSF digital feedback.

Common Misspellings

MDD-093C-N-030-N2L-110GR0

MDD093C N 030 N2L 110GR0

MDD093C-N-030-N2L-110-GR0

MDD093C-N-030-N2L-110-GRO

MDD093C-N-030-N2L-110GRO

MDD093CN030N2L110GR0

MDD93C-N-030-N2L-110GR0

MDDO93C-N-030-N2L-110GR0

MDDO93C-N-O3O-N2L-11OGRO

mdd093c-n-030-n2l-110gr0

Internal Product Review

The MDD093C-N-030-N2L-110GR0 receives recognition for its steady functionality. It is appreciated for fitting into systems without issues and delivering reliable performance. Many reviews highlight its consistent behavior during extended use. The motor is chosen for its ability to handle tasks without unnecessary complications, making it practical for professional needs.
