R911256397 (MDD093C-N-030-N2M-110PA0)

MDD Synchronous Motors

Rated 4.1 stars (11 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch MPN R911256397 (MDD093C-N-030-N2M-110PA0) is an AC servo motor from the MDD series, engineered for operation with either natural convection or surface cooling, directly affecting thermal performance and output characteristics. Continuous torque at standstill is 19.5 Nm with natural convection and 20.8 Nm with surface cooling; corresponding continuous currents are 32.2 A and 34.3 A. The nominal speed is 3000 min⁻¹. The motor utilizes a multiturn absolute encoder and digital servo feedback, and features a flange-mount configuration with a DIN 6885-1 keyway shaft, 110 mm centering diameter, shaft seal, and standard housing. The operating temperature range is 0 to 45°C, the ingress protection is rated at IP65, and the connection type is a side A connector. The unit does not include a holding brake and provides a standard shaft end configuration.

Technical Specifications

Product Line
Bosch MDD AC Servo Motor

Continuous Output Torque at Standstill (Natural Convection)
19.5 Nm

Continuous Output Torque at Standstill (Surface Cooling)
20.8 Nm

Nominal Motor Speed
3000 RPM

Shaft Design
Shaft with keyway (DIN 6885-1 standard)

Blocking Brake
No

Centering Diameter
110mm

Length of Motor Housing
386mm

Motor Weight
22kg

Mounting Style
Flange-mounted

Flange Size
140mm

Housing Protection Standard
IP65

Optimal Operating Temperature
0 to 45 degrees Celsius

Continuous Current Output at Standstill (Natural Convection)
32.2 Amps

Continuous Current Output at Standstill (Surface Cooling)
34.3 Amps

Thermal Time Constant (Natural Convection)
50 minutes

Thermal Time Constant (Surface Cooling)
45 minutes

Power Connection Location
Side A of the housing.
