R911265587 (MDD093B-N-040-N2M-110PA1)

Name: R911265587 (MDD093B-N-040-N2M-110PA1)
Brand: Indramat Motors
SKU: MDD093B-N-040-N2M-110PA1
Price: 154.00 USD
Availability: InStock
Rating: 4.5 (4 reviews)

MDD Synchronous Motors

Rated 4.5 stars (4 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911265587 (MDD093B-N-040-N2M-110PA1) is a Bosch Rexroth AC servo motor engineered for applications requiring precise motion control. This model features a standard 093 frame size with a 110 mm centering diameter, a keyed output shaft with shaft seal, and a standard housing. The motor delivers a nominal speed of 4000 min⁻¹ and a continuous standstill torque of 14.5 Nm. An integrated multiturn absolute encoder provides digital servo feedback for accurate positioning. The blocking brake supplies 11 Nm holding torque. Electrical connections are positioned on side A via connector. Heat dissipation is achieved through natural convection and surface cooling. Ensure operation does not exceed 45°C ambient temperature or 1000 m site elevation. Weight: approximately 16.5 kg. Observe all recommended safety procedures during installation and operation.

Technical Specifications

Cooling System
Natural Convection and Surface Cooling

Nominal Speed
4000 RPM

Feedback Type
Digital Servo Feedback

Encoder
Integrated Multiturn Absolute Encoder

Mounting
Centering Diameter 110 Millimeters

Output Shaft
With Keyway

Wiring
Power Connection to Side A

Brake
Blocking Brake, 11 Nm Holding Torque

Ambient Temperature Range
Up to 45 Degrees Celsius

Site Elevation
Up to 1000 Meters

Weight
16.5 Kilograms

Rated Output Torque
14.5 Nm

Peak Torque Output
45.1 N

Rated Current Output
36.6 Amps

Peak Current Output
164.8 Amps

Frequently Asked Questions

Do the blocking brakes in the MDD093B-N-040-N2M-110PA1 improve operational safety?

Yes, the blocking brake securely holds the motor shaft when power is cut. This prevents unintended movement in vertical or safety-sensitive applications.

Why is the shaft seal included in the MDD093B-N-040-N2M-110PA1?

The shaft seal protects against dust, oil, and contaminants entering the motor. This ensures durability and extended operational reliability.

Does the keyway shaft of the MDD093B-N-040-N2M-110PA1 improve load handling?

Yes, the keyway shaft ensures a secure mechanical connection. It prevents slippage and improves performance under high torque conditions.

How does the digital servo feedback (DSF) of the MDD093B-N-040-N2M-110PA1 enhance precision?

DSF enables high-resolution communication between motor and drive controller. This ensures precise positioning and fast dynamic response.

Why is the side A connector orientation important in the MDD093B-N-040-N2M-110PA1?

Side A orientation supports better cable management in compact spaces. It reduces wiring stress and simplifies serviceability.

Common Misspellings

MDD-093B-N-040-N2M-110PA1

MDD093B N 040 N2M 110PA1

MDD093B-N-040-N2M-110-PA1

MDD093BN040N2M110PA1

MDD93B-N-040-N2M-110PA1

MDDO93B-N-040-N2M-110PA1

MDDO93B-N-O4O-N2M-11OPA1

mdd093b-n-040-n2m-110pa1

Internal Product Review

The MDD093B-N-040-N2M-110PA1 is a small motor from Bosch Rexroth Indramat used in digital drive controllers. It provides 14.5 Nm continuous torque at standstill, an on-board multiturn absolute encoder with digital servo feedback, and an 11 Nm holding brake. This motor is utilized in sophisticated precision automation systems.
