R911276562 (MDD093B-N-040-N2L-110PA1)
Request a quote
Description
Rated 4.3 with 8 reviews
The Bosch R911276562 (MDD093B-N-040-N2L-110PA1) is a high-powered, digital AC servo motor in the MDD093 lineup, perfectly suited for tool-changing devices and cutting machines due to its high power density. Equipped with an in-built blocking brake and an output shaft with a keyway, it also features a shell designed for natural convection or surface cooling and digital servo feedback. Connection for the power cable is located on side A of the motor housing with a 110mm centering diameter. Mounted through four points on a 140mm flange, the motor shaft is 24mm in diameter. It weighs 16.5kg and is approximately 327mm long, with a nominal speed of 4000 RPM. The motor has torque options depending on cooling methods, and an IP65 rated housing. It operates within a range of 0 to 45 degrees Celsius and up to 1,000 meters altitude. To ensure proper operation, handling should only be undertaken by trained professionals.Specs
Product Line: MDD
Centering Diameter: 110 mm
Mounting: Flange with four holes
Flange Size: 140 mm
Motor Shaft Diameter: 24 mm
Motor Housing Length: 327 mm
Weight: 16.5 kg
Nominal Motor Speed: 4000 RPM
Continuous Torque at Standstill (Convection Cooling): 14.5 Nm
Continuous Current at Standstill (Convection Cooling): 36.6 Nm
Continuous Torque at Standstill (Surface Cooling): 20 Nm
Continuous Current at Standstill (Surface Cooling): 50.5 Nm
Blocking Brake Actuation: Electrically at 24 Volts DC
Brake Holding Torque: 11 Nm
Brake Weight: 0.5 kg
Housing Protection Class: IP65
Operating Temperature: 0 to 45 degrees Celsius
Operating Altitude: 0 to 1000 meters
Handling and Operation: Trained personnel only.
Centering Diameter: 110 mm
Mounting: Flange with four holes
Flange Size: 140 mm
Motor Shaft Diameter: 24 mm
Motor Housing Length: 327 mm
Weight: 16.5 kg
Nominal Motor Speed: 4000 RPM
Continuous Torque at Standstill (Convection Cooling): 14.5 Nm
Continuous Current at Standstill (Convection Cooling): 36.6 Nm
Continuous Torque at Standstill (Surface Cooling): 20 Nm
Continuous Current at Standstill (Surface Cooling): 50.5 Nm
Blocking Brake Actuation: Electrically at 24 Volts DC
Brake Holding Torque: 11 Nm
Brake Weight: 0.5 kg
Housing Protection Class: IP65
Operating Temperature: 0 to 45 degrees Celsius
Operating Altitude: 0 to 1000 meters
Handling and Operation: Trained personnel only.
