The MKE047B-144-GP1-BENN is a size 47 synchronous servo motor with 144 winding turns and four pole pairs. Manufactured by Bosch Rexroth Indramat in the MKE Synchronous Motors series, it features ATEX housing and class F insulation. It has a 2.2 Nm holding brake, B-side terminal box connection, and a shaft with 6885 keyway.

Technical Specifications

Connection Type
Terminal box

Connection Direction
B-side

Holding Brake
With holding brake

Holding Brake Torque
2.2 Nm

Housing Standard Compliance
ATEX

Number of Pole Pairs
4

Insulation Class
155 (F)

Shaft Design
Shaft with keyway

Shaft Seal
Yes

Shaft Detail
DIN 6885 Keyway

Product type
Servo Motor for potentially explosive areas

Winding
144

Motor Size
47
