MKE098B-047-PP0-BENN
MKE Synchronous Motors
The Bosch Rexroth Indramat MKE098B-047-PP0-BENN is a servo motor in the MKE Synchronous Motors series. It features a terminal box connection and a shaft with DIN 6885 keyway, delivering 43.5 Nm maximum torque. Compliant with ATEX, rated 0...+40 °C, with 8.400 Ω winding resistance@20 °C and 91.0 V/min⁻¹ voltage constant@20 °C.
Technical Specifications
Connection Type
Terminal box
Connection Direction
B-side
Holding Brake
Without holding brake
Housing Standard Compliance
ATEX
Maximum Torque
43.5 Nm
Ambient Temperature
0...+40 °C
Shaft Design
Shaft with keyway
Shaft Detail
DIN 6885 Keyway
Product type
Servo Motor for potentially explosive areas
Winding Resistance @ 20°C
8.400 Ohm
Voltage Constant @ 20°C (K_EMK 1000)
91.0 V/min⁻¹
Motor Size
98
