R911271770 (MKE045B-144-KG0-KN)

MKE Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911271770 (MKE045B-144-KG0-KN) is an industrial servo motor designed for application in production systems, optimized for kinetic energy transfer. It features a compact build, measuring approximately 283 mm in length and 78 mm in thickness, with a mass of 5.5 kg. This model supports installation in any orientation and employs natural convection for cooling. It utilizes a steel shaft with a keyway compliant with DIN 6885, and includes a frontal centering hole and seal. The shaft thread is a DIN 332 'DS' type. Motor winding is type 144 and is configured without a holding brake. The unit supports connection via a terminal box, oriented at the top. Ball bearings are grease-lubricated, rated for a service life of approximately 30,000 hours. Electromagnetic emissions are present and physical proximity should be considered where sensitive equipment or implants are in use. The winding inductivity measures 1.8 mH and the thermal time constant is 30 minutes. Maximum allowable axial and radial loads are 10 m/s² and 30 m/s², respectively. This servo motor is suitable for use in potentially explosive environments and motor size is 45.

Technical Specifications

Main Use
Kinetic Energy Transmission in Industrial Machines

Length
283 millimeters

Thickness
78 millimeters

Weight
5.5 kilograms

Installation Position
Any

Cooling Method
Natural Convection

Connector
Steel Shaft With DIN 6885 Keyway

Winding Inductivity
1.8 millihenry

Thermal Time Constant
30 minutes

Expected Service Life (Ball Bearings)
30000 hours

Maximum Permissible Axial Load
10 meters per second square

Maximum Permissible Radial Load
30 meters per second square
