R911284164 (MKE045B-144-GP0-KN)

MKE Synchronous Motors

In Stock, Shipping Varies

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911284164 (MKE045B-144-GP0-KN) is an industrial servo motor engineered for environments requiring protection against dust, water jets, seawater, mineral oils, and dilute acids, featuring an IP65 housing with a black RAL9005 finish. This model integrates an optical encoder for real-time motion-to-digital signal conversion, supporting integration with drive controllers. The device sustains a maximum current of 22.6 A, peak torque of 11.3 Nm, and operates at speeds up to 7000 RPM, with an operational noise level of 63 dB. The motor must be installed at elevations up to 1000 meters and can operate at temperatures up to 40°C. It is provided without a holding brake, has a shaft with keyway according to DIN 6885, includes a shaft seal, employs a terminal box connection direction on top, uses winding code 144, and is designated as a 45 frame size servo motor for potentially explosive areas.

Technical Specifications

Type
Industrial Motor

Protection Class
IP65

Paint Color
Black (RAL9005)

Encoder Type
Optical

Maximum Current
22.6 Amperes

Maximum Torque
11.3 Newton meters

Maximum Speed
7000 revolutions per minute

Leakage Current
Exceeds 3.5 milliamperes

Sound Pressure Level
63 decibels

Maximum Operation Temperature
40 degrees Celsius

Maximum Installation Height
1000 meters above sea level
