R911292601 (MKE047B-144-AG0-BENN)

MKE Synchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth servo motor R911292601 (MKE047B-144-AG0-BENN) is designed for use in potentially explosive areas, conforming to ATEX and IP65 standards. It features a 47 mm motor size, 144 winding, and a 4-pole design, with a terminal box connection on the B-side. The motor incorporates a Singleturn Hiperface optical encoder (model S1, 128 increments) for indirect position feedback. It provides a maximum torque of 11.3 Nm, continuous torque of 2.7 Nm at standstill, and operates up to 7000 rpm. The unit has a plain shaft with a frontal centering hole, shaft seal, and a DIN 332 'DS' compliant thread. Its insulation class is 155 (F), and it is designed to operate in ambient temperatures from 0 to 40°C. The motor weighs 5.5 kg and emits approximately 63 dB(A) during operation.

Technical Specifications

Encoder Type
Singleturn Hiperface Optical Encoder

Maximum Torque
11.3 Nm

Maximum Speed
7000 rpm

Continuous Torque at Standstill
2.7 Nm

Weight
5.5 kg

Noise Level
63 dB(A)

temperature Range
0 to 40 C

Housing Design Standard
ATEX

Protection Standard
IP65
