R911292977 (MKE047B-144-KP0-BUNN)

MKE Synchronous Motors

In Stock, Shipping Varies

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MPN R911292977 (MKE047B-144-KP0-BUNN) is a Bosch Rexroth MKE047 series brushless servo motor designed for demanding industrial applications, particularly in potentially explosive environments. It features a maximum torque of 11.3 Nm and operates at a continuous current of 22.6 A with a winding resistance of 1.8 Ohm. The motor has a rotor inertia of 0.00017 kgm³ and can reach speeds up to 7000 rpm across its four-pole pairs. The shaft, with a DIN 6885 keyway and shaft seal, provides secure output, while an optical encoder ensures precise positional feedback. The housing carries an IP65 protection rating and complies with UL/CSA standards. Connection is via a B-side terminal box, it is built without a holding brake, and supports insulation class 155 (F). The unit is specified for operation between 0 to +40°C with derated performance up to +55°C.

Technical Specifications

Type
Brushless Servo Motor

Operating Environment
Severe

Permissible Ambient Temperature
0 to +40 degree Celsius

Maximum Torque
11.3 Nm

Operating Current
22.6 A

Motor Winding Resistance
1.8 Ohm

Rotor Inertia
0.00017 kgm3

Maximum Speed
7000 RPM

Output Shaft
Keyway (with shaft sealing ring)

Encoder
Optical

Holding Brake
Not Included

Maximum Operating Temperature
+55 degree Celsius (with 20% derating)

Protection Class
IP 65

Compliance
American Standards

Delivery
Worldwide

Additional Items
User Manual in Native Language
