R911292978 (MKE047B-144-GP0-BUNN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911292978 (MKE047B-144-GP0-BUNN) servo motor is engineered for industrial environments requiring high reliability and quiet operation, with noise pressure below 65 dB under standard conditions. This unit features a maximum speed of 7000 RPM and maximum current draw of 22.6 A. At standstill, a continuous current of 5.0 A enables the production of a constant torque of 2.7 Nm. It uses a B05 flange assembly, weighs approximately 3.5 kg, and incorporates grease-lubricated bearings cooled by natural convection. The motor is constructed to comply with UL/CSA standards, uses insulation class 155 (F), provides four pole pairs, and supports a shaft with keyway per DIN 6885 and shaft seal. The connection is made via a terminal box on the B-side, without a holding brake, and the design accommodates shielded power and encoder cables to mitigate electrical interference. It is classified as a servo motor suitable for potentially explosive areas, with winding type 144 and size 47.

Technical Specifications

Application
Industrial Production Systems

Noise Level
Less than 65 Decibels

Integrated Battery
Yes

Quality Standard
International

Peak Speed
7000 revolutions per minute

Max Current Draw
22.6 Amperes

Standstill Current
5.0 Amperes

Continuous Torque
2.7 Newton meters

Max Torque
11.3 Newton meters

Weight
3.5 kilograms

Flange Assembly
B05

Heat Regulation
Natural Convection, Grease-lubricated Bearings

Power Cable
Required, Properly Shielded

Encoder Cable
Required, Properly Shielded
