R911294249 (MKE047B-144-KG1-BENN)

MKE Synchronous Motors

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911294249 (MKE047B-144-KG1-BENN) is a MKE047 series brushless servo motor engineered for operation in potentially explosive environments, compliant with ATEX standards. The motor delivers a top torque of 11.3 Nm, a peak current of 22.6 A, and supports maximum speeds up to 7000 rpm. It is equipped with an electronic-release holding brake rated at 2.2 Nm holding torque, operating at 24 V and a rated current of 0.34 A. The plain shaft features a frontal centering hole and DS thread compliant with DIN 332, supported by a shaft seal. The connection direction is B-side with a terminal box connection type. The unit has a winding inductivity of 1.8 mH, 4 pole pairs, insulation class 155 (F), and a mass of 5.5 kg. It is suitable for use within an ambient temperature range of 0–40°C and manufactured with a tolerance of ±5%.

Technical Specifications

Product Type
Servo Motor

Power Source
AC

Maximum Torque
11.3 Nm

Maximum Current
22.6 A

Holding Brake Torque
2.2 Nm

Holding Brake Voltage
24 V

Holding Brake Current
0.34 A

Shaft Type
Plain

Weight
5.5 kg

Protection Class
IP 65

Insulation Class
155

Maximum Speed
7000 rpm

Pole Pairs
3

Winding Inductivity
1.8 mH

Ambient Temperature
0 to +40 degree Celsius

Manufacturing Tolerance
±5 %

Compliance Standard
European Standard

Shipping Availability
Worldwide

Product Availability
Yes at Indramat USA
