R911296025 (MKE047B-144-KP0-BENN)

MKE Synchronous Motors

In Stock, Shipping Varies

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911296025 (MKE047B-144-KP0-BENN) is a brushless servo motor engineered for use in demanding environments, including potentially explosive areas as defined by ATEX standards. It features a rated current of 22.6 A and delivers a maximum torque of 11.3 Nm. Continuous standstill torque is 2.7 Nm at a standstill current of 5 A. The winding resistance is 1.8 Ohm, and the motor contains four pole pairs and an inertia of 0.00017 kgm³. Shaft design includes a keyway per DIN 6885 with a shaft seal. The motor supports speeds up to 7,000 rpm and operates at a noise level of 63 ±3 dB(A). The insulation class is 155 (F), with IP65 protection against dust and liquid jets. An integrated optical encoder enables precise speed and position control. The motor is suitable for ambient temperatures between 0 and 40°C, is supplied without a holding brake, and uses a terminal box for connection on the B-side.

Technical Specifications

Product Type
Brushless Servo Motor

Class Protection
IP 65

Rated Current
22.6 A

Maximum Torque
11.3 Nm

Continuous Torque at Standstill
2.7 Nm

Continuous Current at Standstill
5 A

Winding Resistance
1.8 Ohm

Pole Pairs
3

Moment of Inertia
0.00017 kgm3

Maximum Velocity
7,000 rpm

Sound Pressure Level
63.0 (±3) dB

Embedment Control System
Optical Encoder

Equipped Holding Brake
No

Permissible Ambient Temperature
0 – 40 degree Celsius
