R911296026 (MKE047B-144-KP1-BENN)

MKE Synchronous Motors

  In Stock, Ships in 3-5 Days
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911296026 (MKE047B-144-KP1-BENN) is a Rexroth Indramat industrial synchronous servo motor designed for use in potentially explosive environments, compliant with ATEX and UL/CSA regulations. It features an IP65-rated enclosure for protection against dust and water jets. The motor has a winding designation of 144, four pole pairs, and uses a shaft with a DIN 6885 keyway and shaft seal. The connection is via a terminal box on the B-side. It provides a maximum speed of 7000 RPM, peak current of 22.6 A, and a voltage constant of 36.3 V/min at 20°C. The holding brake torque is 2.2 Nm. The device uses Class 155 (F) insulation and integrated grease-lubricated bearings. The motor, with a mass of 5.5 kg and size 47, is suitable for high-frequency start-stop operations in demanding industrial applications.

Technical Specifications

Production Requirements
ATEX and UL/CSA

Type
Permanent magnet motor

Protection Class
IP65

Peak Speed
7000 revolutions per minute

Max Current
22.6 Amperes

Voltage Constant
36.3 volts per minute (at 20 degrees Celsius)

Weight
5.5 kilograms
