R911299015 (MKE047B-144-KG0-BENN)

MKE Synchronous Motors

In Stock, Ships in 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911299015 (MKE047B-144-KG0-BENN) is a Bosch Rexroth synchronous servo motor designed for flange assembly type B05 and compliant with ATEX housing and insulation class 155 (F) per DIN EN 60034-1. Featuring a plain shaft with frontal centering hole and DIN 332 'DS' shaft thread, the motor offers IP65 enclosure protection and a terminal box connection on the B-side. It is constructed for use in potentially explosive environments and integrates a built-in data memory. The unit operates with a winding code 144, 4 pole pairs, and is specified without a holding brake. Electrical characteristics include 2.7 Nm continuous torque at standstill (60 K), 11.3 Nm maximum torque, 22.6 A maximum current, 1.8 mH inductivity, and a maximum velocity of 7000 rpm. The sound pressure level is rated at 63 dB(A), and the motor weighs 5.5 kg. The SUP-M02-MKE accessory kit is included for connectivity. Maintenance and connector adjustments must be performed with the device de-energized and in non-hazardous environments. Underwater operation is not permitted.

Technical Specifications

flange assembly
B05

accessory kit included
SUP-M02-MKE

length code
B

insulation class
155

cooling down period
140 minutes

operational reliability
high

recommended usage
printing and packaging machines

special feature
data memory

underwater usage
not applicable

holding brake
non-existent

housing standard
ATEX

sound pressure level
63 +/-3 dBA

transportation
via reputed logistics freight carriers
