R911299766 (MKE098B-047-KP0-BUNN)

Name: R911299766 (MKE098B-047-KP0-BUNN)
Brand: Indramat Motors
SKU: MKE098B-047-KP0-BUNN
Price: 551.00 USD

MKE Synchronous Motors

Front Right

Call for Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911299766 (MKE098B-047-KP0-BUNN) is a servo motor designed by Bosch Rexroth for use in potentially explosive industrial environments. It features a DIN-compliant flange for straightforward machine integration, with a B-side terminal box connection and no holding brake. The motor uses a shaft with a DIN 6885 keyway and operates with a maximum current of 44.3 A (RMS). With a rotor moment of inertia of 0.00430 kg·m² and insulation class 155 (F), the unit is constructed to limit noise and heat generation during operation. It maintains performance under IP65 environmental protection, resisting exposure to dirt, water jets, non-corrosive oils, and similar substances. Compliance with UL and CSA housing standards is provided.
