R911305252 (MKE047B-144-GG1-BUNN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911305252 (MKE047B-144-GG1-BUNN) is a superior industrial servo motor manufactured by Rexroth Indramat, noted for its durability under adverse operational circumstances. Its hardened casing prevents water jet infiltration and solid materials. It demonstrates astonishing performance levels, operating at 90% efficiency for more than five years without any maintenance required under perfect conditions. It is versatile and best suited for machines involved in metal forming, food and paper processing among others, and may necessitate connecting extra sensors and actuators for optimal servo system operation. The synchronous motor features a holding brake with a torque of 2.2-newton meters, a continuous torque output of 5.7-newton meters and can reach 7000 RPM. Built with a hiperface single turn absolute optical encoder, it has a margin of error of 120 signal seconds. The motor falls under the 155 insulation class, operates between 0 to 40 degrees Celsius, and weighs 5.6 kgs. Global shipment is available, accompanied by a one-year warranty from Indramat USA.

Technical Specifications

Motor Function
Industrial Servo Motor

Motor Efficiency
90%

Motor Lifespan
5 years (under ideal conditions)

Brake
Yes

Holding Torque
2.2 Nm

Brake Current
0.34 Amperes

Continuous Current at Standstill
5 Amperes

Continuous Torque at Standstill
5.7 Nm

Maximum Speed
7000 RPM

Encoder Type
Hiperface single turn absolute optical

Encoder System Accuracy
120 signal seconds

Maximum Encoder Current
60 milliamperes

Motor Weight
5.6 kg

Pole Pairs
3

Thermal Time Constant
30 minutes

Insulation Class
155 (according to DIN EN 60034-1)

Permissible Ambient Temperature
0 to 40 degrees Celsius
